Medium trykkugleventiler
|
2- måde |
|||||||||||||
|
Del INGEN. |
Åbning I. |
Dimension i. (Mm) |
|||||||||||
|
A |
B |
C |
D |
F |
G |
H |
J |
K |
L |
M |
BlokThk |
||
|
Ss-mpbvf 4- |
1/4 |
4.09 (104) |
4.19 (106) |
2.00 (50.8) |
3.33 (84.5) |
1.13 (28.6) |
1.50 (38.1) |
0.75 (19.1) |
0.43 (10.9) |
0.28 (7.1) |
2.31 (58.6) |
/ |
1.00 (25.4) |
|
SS-MBV-F 6- |
3/8 |
4.84 (121) |
5.53 (140) |
3.00 (76.2) |
4.96 (126) |
1.38 (34.9) |
2.00 (50.8) |
1.00 (25.4) |
0.41 (10.3) |
0.28 (7.1) |
2.95 (74.9) |
/ |
1.38 (34.9) |
|
SS-MBV-F 8- |
1/2 |
5.39 (137) |
7.73 (196) |
4.12 (105) |
/ |
1.66 (42.2) |
3.00 (76.2) |
1.50 (38.1) |
0.50 (12.7) |
0.28 (7.1) |
3.52 (89.4) |
/ |
1.75 (44.5) |
|
3-vej |
|||||||||||||
|
Del INGEN. |
Åbning I. |
Dimension i. (Mm) |
|||||||||||
|
A |
B |
C |
D |
F |
G |
H |
J |
K |
L |
M |
BlokThk |
||
|
Ss-mbv-f 3-3 w- |
3/16 |
5.00 (127) |
4.69 (119) |
2.50 (63.5) |
3.33 (84.5) |
1.13 (28.6) |
1.50 (38.1) |
0.75 (19.1) |
0.43 (10.9) |
0.28 (7.1) |
2.25 (57.2) |
0.48 (12.3) |
1.00 (25.4) |
|
Ss-mbv-f 6-3 w- |
3/8 |
5.88 (149) |
5.53 (140) |
3.00 (76.2) |
4.96 (126) |
1.38 (34.9) |
2.00 (50.8) |
1.00 (25.4) |
0.41 (10.3) |
0.28 (7.1) |
2.95 (74.9) |
1.89 (30.2) |
1.38 (34.9) |
